Technical data
| Name | ARRI Signature Zoom 16-32/T2.8 | ARRI Signature Zoom 24-75/T2.8 | ARRI Signature Zoom 45-135/T2.8 | ARRI Signature Zoom 65-300/T2.8 | ARRI Signature Zoom 65-300/T2.8 |
| Focal length | 16 mm - 32 mm | 24 mm - 75 mm | 45 mm - 135 mm | 65 mm - 300 mm | 110.5 mm - 510 mm |
Lens mount | LPL | LPL | LPL | LPL | LPL |
LDS | LDS-2 or Cooke/i | LDS-2 or Cooke/i | LDS-2 or Cooke/i | LDS-2 or Cooke/i | |
Aperture | T2.8 - T22 | T2.8 - T22 | T2.8 - T22 | T2.8 - T22 | T 4.95 - T39.62 |
MOD from sensor plane (minimum marked distance) | 0.45 m / 1'6" | 0.7 m / 2'6" | 1 m / 3'4" | 1.8 m / 6' | 1.84 m / 6.13' |
MOD from lens front | 0.194 m / 7.64" | 0.412 m / 16.22" | 0.656 m / 25.83" | 1.337 m / 52.52" | 1.337 m / 52.52" |
Length from flange | 212 mm / 8.35” | 244 mm / 9.61" | 300 mm / 11.81” | 420 mm / 16.54” | Extender: 53.8 mm / 2.1'' - Extension by Extender: 36.8mm / 1.4'' - Lens + Extender: 456.8 mm / 18'' |
| Magnification ratio at MOD (Paraxial) | 1:14.2 - 1:7.5 | 1:18.7 - 1:6.2 | 1:16.4 - 1:5.6 | 1:23.1 - 1:5.2 | 1:13.2 - 1:2.9 |
Entrance pupil position (related to image plane, in direction to object) | 221.88 mm / 8.74“ - 220.46 mm / 8.68" | 240.12 mm / 9.45“ - 236.02 mm / 9.29" | 258.50 mm / 10.18" - 184.79 mm / 7.28" | 272.82 mm / 10.74" - -33.44 mm / - 1.32" | 309.66 mm - 3.41 mm |
Angle of view H - V - D for LF Open gate | 98.0° / 77.0° / 109.2° - 59.9° / 44.1° / 69.8° | 75.5° / 56.1° / 86.9° - 27.8° / 19.7° / 33.4° | 44.6° / 31.6° / 53.3° - 15.5° / 10.9° / 18.7° | 31.6° / 22.1° / 38.4° - 7.1° / 5.0° / 8.6° | 19.0° / 13.1° / 23.3° - 4.3° / 3.0° / 5.2° |
| Maximum housing diameter | 157 mm / 6.18" | 124 mm / 4.88" | 117 mm / 4.60" | 170 mm / 6.69" | Extender only: 115 mm / 4.5'' including handles - 170 mm / 6.69" with lens |
Front diameter | 156 mm / 6.14" | 114 mm / 4.49" | 114 mm / 4.49" | 156 mm / 6.14" | 156 mm / 6.14" |
Weight (lens only) | 3.2 kg / 7 lb 0.9 oz | 3.7 kg / 8 lb 3 oz | 3.6 kg / 8 lb 2.5 oz | 8.1 kg / 17 lb 13.7 oz | Extender: 0.58 kg / 1 lb 4 oz - Lens + Extender: 8.7kg / 19 lb 2.9 oz |
Item number meter | KK.0038601 | KK.0038603 | KK.0038605 | KK.0038607 | Extender separately |
Item number feet | KK.0038602 | KK.0038604 | KK.0038606 | KK.0038608 | Extender separately |
