Optical System
Changeable optics
Light Aperture
42 mm / 1,66", without optics
Beam Angle
80° Half Peak Angle, without optics
Weight
Fixture only: 11,7 kg / 25.8 lbs
Manual Version: 14,2 kg / 31.3 lbs
Pole Op Version: 14,9 kg / 32.9 lbs
Handling
Aluminum yoke with quick release, high strength tilt lock, pole operation option (pan and tilt)
Mounting
28 mm Spigot (Junior Pin)
Tilt Angle
+/-90° in dry location, +75° / -90° in wet location with rain cover
Voltage Input Range
100 - 240 V~, 50 - 60 Hz
Power Consumption
400 W Nominal, 500 W Maximum
Mains Power Connection
powerCON TRUE1 TOP
(Bare Ends / Schuko / Edison, Japanese, Chinese cables available)
Battery Connector
3-Pin XLR Connector (Pin 1: negative, Pin 2: positive)
Battery DC Voltage Range
48 - 52 V⎓
White Light
calibrated 2,000 K to 20,000 K continuously variable correlated color temperature
Color Modes
CCT, HSI, individual color, gel selection, x/y coordinates, source matching, lighting effects, and color sensor mode
Color Temperature Tolerance
3,200 to 5,600 K: +/- 100 K (nominal), +/- 1/8 Green-Magenta (nominal)
High Color Rendition
3.200 to 5.600 K:
CRI Average > 98
TLCI Average > 95
TM-30 Average > 94
Green-Magenta Adjustment
Continuously adjustable between Full Minusgreen to Full Plusgreen
Dimming
Smooth, 100 – 0%, continuously, linear / exponential / logarithmic / „S“ curve
Connectivity
Removable Control Panel via PoE, 5-pin XLR in and through, EtherCON in and through, 2 x USB-A, USB-C, SD Card, Camera Sync Input
Control Options
Wireless control via LumenRadio CRMX* (DMX & RDM), Full E1.20 RDM standard implementation with custom & standard RDM commands
* Brand: LumenRadio AB, Equipment: CRMX TiMo, Model: 200-1502, Product: Orbiter 2.4G Wireless Control Module, Frequency Range: 2402 - 2480 MHz, Frequency of Operation: 2402 - 2480 MHz, Power Output: 17.51 dBm, Number of Channels: 79, Channel Spacing: 1 MHz, Modulation Type: GFSK
Housing Color
Blue/silver, Black
Ambient Temperature Operation
-20 to +45º C (-4 to +113º F)
IP Rating
IP 20 without Rain Cover, IP24 with Rain Cover L2.0037805
Estimated LED Lifetime (L70)
50,000 hours
Estimated Color Shift Over Lifetime (CCT)
+/- 5 %
Certifications & Declarations of Conformity
CB, CE, UKCA, ENEC, cNRTLus, ICES, FCC, PSE, MIC, KC, SRRC, RCM, IFT, TRA, ETA, ANATEL, ENACOM, NTC
FCC Statement
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Canada: CAN ICES-3 (B)/NMB-3(B)
All specifications are preliminary typical values. Subject to change without notice.
