Technical data for SkyPanel Classic

SkyPanel
S30-C

SkyPanel
S120-C

SkyPanel
S360-C

Type of Lamphead

LED Soft Light

LED Soft Light

LED Soft Light

Optical System

Swappable Soft Diffusion Panels

Swappable Soft Diffusion Panels

Swappable Soft Diffusion Panels

Light Aperture

355 x 300 mm / 14 x 11.8"

1290 x 300 mm / 50.8 x 11.8"

1280 x 870 mm / 50.4 x 34.4"

Beam Angle

105º Half Peak Angle

105º Half Peak Angle

105º Half Peak Angle

Lamp Type

RGBW LED Light Engine

RGBW LED Light Engine

RGBW LED Light Engine

White Light

2,800 K to 10,000 K continuously correlated color temperature

2,800 K to 10,000 K continuously correlated color temperature

2,800 K to 10,000 K continuously correlated color temperature

Colored Light

Full RGB+W color gamut with Hue and Saturation control

Full RGB+W color gamut with Hue and Saturation control

Full RGB+W color gamut with Hue and Saturation control

Green-Magenta-Adjustment

Continuously adjustable (Full Minus- to Full Plusgreen)

Continuously adjustable (Full Minus- to Full Plusgreen)

Continuously adjustable (Full Minus- to Full Plusgreen)

Color Rendition

Color Temperature Tolerance

+/- 100 K (nominal)

+/- 1/8 Green-Magenta (nominal)

+/- 100 K (nominal)

+/- 1/8 Green-Magenta (nominal)

+/- 100 K (nominal)

+/- 1/8 Green-Magenta (nominal)

Dimming

0 to 100% continuous

0 to 100% continuous

0 to 100% continuous

Light Output in Battery Mode

100% of total output

50% of total output

n.a.

Mechanical

Versions

Manual, Pole Operated

Manual, Pole Operated, Center Mount

Manual

Handling

Aluminium Yoke, High-Strength Tilt Lock / Steel Yoke, Pole Operation for Pan & Tilt

Aluminium Yoke, High-Strength Tilt Lock / Steel Yoke, Pole Operation for Pan & Tilt / Center Mount Yoke

Carbon Fiber Yoke, Dual High-Strength Tilt Lock

Mounting

16 mm / 28 mm Combo Pin

Spigot 28 mm Junior Pin

Spigot 28 mm Junior Pin

Housing Colors

blue/silver, black

blue/silver, black

blue/silver

Tilt Angle

+/- 90º

+/- 90º

+/- 90º

Weight
Fixture only
Manual
Pole operated

approx. 6.3 kg / 13.9 lbs
approx. 7.7 kg / 17 lbs
approx. 9.5 kg / 20.9 lbs

approx. 12.9 kg / 28.4 lbs
approx. 16.5 kg / 36.4 lbs
approx. 20.5 kg / 44.2 lbs

approx. 40 kg / 89 lbs
Carbon Yoke & Short Yoke: 45 kg / 98 lbs

Weight
in kg / lbs net packed*

Manual Version: approx. 14 kg / 31 lbs
Pole Operated Version: approx. 16 kg / 34 lbs

Manual Version: approx. 26 kg / 57 lbs
Pole Operated Version: approx. 29 kg / 65 lbs
Center Mount Version approx.: 24 kg / 53 lbs

-

Measurements (HxWxL) incl. Pin in mm / inch*

Manual Version:
499 x 507 x 133 mm / 19.6 x 19.9 x 5.2"
Pole Operated Version:
567 x 504 x 133 mm / 22.3 x 19.8 x 5.2"

Manual Version:
588 x 1467 x 133 mm / 23.1 x 57.7 x 5.2"
Pole Operated Version:
615 x 1439 x 133 mm / 24.2 x 56.6 x 5.2"

1237 x 1594 x 203 mm / 48.7 x 62.8 x 8.0"

Measurements (HxWxL) excl. Pin in mm / inch*

Manual Version:
426 x 507 x 133 mm / 16.8 x 19.9 x 5.2"
Pole Operated Version:
452 x 504 x 133 mm / 17.8 x 19.8 x 5.2"

Manual Version:
473 x 1467 x 133 mm / 18.6 x 57.7 x 5.2"
Pole Operated Version:
500 x 1439 x 133 mm / 19.7 x 56.6 x 5.2"

1122 x 1594 x 203 mm / 44.2 x 62.8 x 8.0"

Measurements (HxWxL) Packed size in mm / inch*

470 x 665 x 300 mm / 18.5 x 26.2 x 11.8"

500 x 1500 x 300 mm / 19.7 x 59.1 x 11.9"

-

Control Options

Control

On-Board Controller, 5-Pin DMX In and Through EtherCon LAN network connectivity, USB-A, Art-Net, sACN

On-Board Controller, 5-Pin DMX In and Through EtherCon LAN network connectivity, USB-A, Art-Net, sACN

On-Board Controller, 5-Pin DMX In and Through EtherCon LAN network connectivity, USB-A, Art-Net, sACN

Remote Device Management (RDM)

DMX Setup, Hour Counter and Standard RDM Commands

DMX Setup, Hour Counter and Standard RDM Commands

DMX Setup, Hour Counter and Standard RDM Commands

Software Interface - Ethernet

DMX Setup, Fixture Stats, Frimware Upgrade through PC or MAC

DMX Setup, Fixture Stats, Frimware Upgrade through PC or MAC

DMX Setup, Fixture Stats, Frimware Upgrade through PC or MAC

Software Interface - USB-A

Firmware Upgrade via Flash Drive

Firmware Upgrade via Flash Drive

Firmware Upgrade via Flash Drive

Wireless Interface

via SkyLink Receiver

via SkyLink Receiver

LumenRadio CRMX built in

Features

Light Modes

CCT, HSI, Gel Mode, Source Matching, RGBW, x,y Coordinates

CCT, HSI, Gel Mode, Source Matching, RGBW, x,y Coordinates

CCT, HSI, Gel Mode, Source Matching, RGBW, x,y Coordinates

Special Modes

Low End, Stage, Tungsten, High Speed Mode

Low End, Stage, Tungsten, High Speed Mode

Low End, Stage, Tungsten, High Speed Mode

Effects

Club Lights, Cop Car, Explosion, Fire, Fluorescent Flicker, Paparazzi and more via SkyPanel Effects

Club Lights, Cop Car, Explosion, Fire, Fluorescent Flicker, Paparazzi and more via SkyPanel Effects

Club Lights, Cop Car, Explosion, Fire, Fluorescent Flicker, Paparazzi and more via SkyPanel Effects

Electrical (Lamphead)

Lamphead Voltage Input

48 V⎓

48 V⎓

54 V⎓

Power Consumption

200 W Maximum

400 W Maximum

1,500 W Maximum

Lamphead Power Connection

Male 3-Pin XLR - 15 A

Male 3-Pin XLR - 15 A

Male 4-Pin Metal Locking- 30 A

Battery Connector

Male 4-Pin XLR - 10 A

Male 4-Pin XLR - 10 A

n.a.

Battery DC Voltage Output

23 to 36 V⎓

23 to 36 V⎓

n.a.

Protection Class / IP Rating

III / IP20

III / IP20

III / IP20

Ambient Temperature Operation

-20 to +45ºC
-4 to +113ºF

-20 to +45ºC
-4 to +113ºF

-20 to +45ºC
-4 to +113ºF

Estimated LED Lifetime (L70)

50,000 hours

50,000 hours

50,000 hours

Estimated Color Shifts over Lifetime (CCT)

+ / - 5%

+ / - 5%

+ / - 5%

Certification & Declaration of Conformity

CE, UKCA, CB, ENEC, cNRTLus, FCC, PSE. Safety & Installation Manual for more Information

CE, UKCA, CB, ENEC, cNRTLus, FCC, PSE. Safety & Installation Manual for more Information

CE, UKCA, CB, ENEC, cNRTLus, FCC, PSE. Safety & Installation Manual for more Information

Power Supply Unit

PSU-Variant

S30 PSU

S60 / S120 PSU

S360 PSU

Power Supply Input Range

48 V⎓

48 V⎓

54 V⎓

Power Supply Output Range

48 V DC

48 V DC

54 V DC

Weight

approx. 2 kg / 4.6 lbs

approx. 4 kg / 7.7 lbs

approx. 11 kg / 24.7 lbs

Measurements (HxWxL) in mm / inch*

91 x 115 x 388 mm / 3.6 x 4.5 x 15.3"

91 x 191 x 383 mm / 3.6 x 7.5 x 15.1"

206 x 240 x 451 mm / 8.1 x 9.4 x 17.7"

Control

On-Board On/Off Switch

On-Board On/Off Switch

On-Board On/Off Switch

Power Input Connection

powerCON TRUE 1 TOP with Schuko, Edison, Bare Ends

powerCON TRUE 1 TOP with Schuko, Edison, Bare Ends

powerCON 32A Schuko, Edison, Japanese, Chinese, Bare Ends

Power Output Connection

Female 3-Pin XLR - 10 A powerCON TRUE1 TOP (Mains Power Through)

Female 3-Pin XLR - 10 A powerCON TRUE1 TOP (Mains Power Through)

Female 4-Pin Metal Locking - 30 A

Mounting

SkyPanel PSU Super Clamp Adapter, SkyPanel Rail Mount Adapter

SkyPanel PSU Super Clamp Adapter, SkyPanel Rail Mount Adapter

SkyPanel PSU Super Clamp Adapter

Certifications

CE, UKCA, CB, ENEC, cNRTLus, PSE

CE, UKCA, CB, ENEC, cNRTLus, PSE

CE, UKCA, CB, ENEC, cNRTLus

Note *Weight and dimensions are rounded values. **Center Mount
