ARRI Ensō Primes SUP 1.0
ARRI is releasing Ensō Prime Software Update Package 1.0, including Lens Firmware LMC V2.6, Lens Bootloader V1.5, and Sensor Firmware V1.0.
Please visit your ARRI Service Center for lens software upgrades.
Features Overview:
- Cooke /i support features automated protocol switching for use on third-party cameras
- LDS-2 features for visual effects
- Precise entrance pupil position information for close focus depth-of-field calculations
- Dynamic focal length information compensates for changes in image magnification at extreme close focus
- New LDS-2 features for attached rear elements
- Automatic detection of attached rear elements for Ensō lenses. This includes:
- All Ensō Vintage Elements (VE 100P, VE 200P, VE 350P, VE 100N, VE 200N, VE 350N)
- Ensō Creative Adapter
- Ensō Prime Net Holder (EP/NH)
- Automatic adjustment of focus, iris and focal length parameters to compensate for variations introduced by the use of Ensō Vintage Elements.
- Automatic detection of attached rear elements for Ensō lenses. This includes:
| Cameras | SUP | Lens metadata type, focus, iris, focal length | Entrance pupil and dynamic focal length | New automatic picture flip | Cooke /i ³⁾ | Detection of rear elements for Ensō lenses | Diopter Compensation |
| ALEXA 35¹⁾ | SUP 2.0.1 | yes | yes | no | not used | no | no |
| ALEXA Mini LF¹⁾ | SUP 7.3 | yes | no | no | not used | no | no |
| ALEXA LF²⁾ | SUP 4.3 | yes | no | no | not used | no | no |
| ALEXA Mini¹⁾ | SUP 6.1.2 | yes | no | no | not used | no | no |
| AMIRA¹⁾ | SUP 6.1.2 | yes | no | no | not used | no | no |
| ALEXA 65 | SUP 5.0 | yes | no | no | not used | no | no |
| ALEXA SXT²⁾ | SUP 2.0 | yes | no | no | not used | no | no |
| ALEXA Classic²⁾ | SUP 11.1.1 | yes | no | no | not used | no | no |
Compatibility Overview
It is not recommended to use older camera SUPs than listed in the table.
¹⁾ with Mini LPL-Mount V1.24 (or higher)
²⁾ with ALEXA LPL-Mount V1.21 (or higher)
³⁾ The support of Cooke /i is intended for cameras from third-party manufacturers
